Copper Line Filter

Get a Price/Quote

Product Details:

IP Rating IP20
Response Time Instantaneous filtering
Interface Terminal connection
Features Compatible with most electrical equipment, easy installation, robust copper construction
Thermal Conductivity High (due to copper body)
Operating Temperature -20C to +60C
Input Single-phase copper line
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Copper Line Filter Price And Quantity

Minimum Order Quantity 200 Piece

Copper Line Filter Product Specifications

Capacity Up to 16A
Frequency 50/60 Hz
Response Time Instantaneous filtering
Weight Approx 350g
Dimension (L*W*H) 120mm x 45mm x 35mm
IP Rating IP20
Rated Voltage 230V AC
Thermal Conductivity High (due to copper body)
Features Compatible with most electrical equipment, easy installation, robust copper construction
Interface Terminal connection
Color Copper
Function Eliminates noise and interference from copper lines
Application Air conditioners, refrigerators, telecom equipment, and other appliances
Input Single-phase copper line
Thickness 1.2 mm (copper body)
Operating Temperature -20C to +60C
Current Rating Up to 16A
Power Supply AC
Usage Line filtering for electrical & electronic devices
Output Filtered copper line output
Components Copper coil, dielectric housing, terminal connectors
Product Type EMI/RFI Line Filter
Supply Voltage 220-240V AC
Power Source AC mains
Size Standard (customizable)

Copper Line Filter Trade Information

Supply Ability 25000 Piece Per Day
Delivery Time 1 Week
Sample Available Yes
Sample Policy Free samples are available
Packaging Details Carton packing available.
Main Domestic Market All India

Product Description

We are among some of the prominent manufacturers and suppliers of a wide assortment of Copper Line Filter. These filters are specially designed by our highly qualified and experienced team of professionals, who leave no stones unturned when it comes to maintain optimum level of quality. Available in various sizes, designs and colors for clients, these filters are properly tested on different quality parameters by our team of professionals. Moreover, our range of Copper Line Filter is well appreciated for high performance, longer service life and cost-effectiveness .

Product details

Filter Type	Line Filter
Power	30W
Phase	Single Phase
Material	Ferrite
Model Name/Number	UU 16
Input Voltage	215V
Current	5Amp
Frequency	60Hz
Cooling Type	Dry Type
Diameter	25mm
Usage/Application	Switching Power Supply

High-Performance Noise Suppression

Engineered for optimal noise reduction, the Copper Line Filter effectively attenuates electromagnetic and radio-frequency interference in copper power lines. Its sophisticated copper coil and dielectric housing work together to deliver up to 50dB attenuation, which keeps sensitive components and appliances running smoothly, free from disruptive signals.

Reliable and Safe Construction

Housed in flame-retardant plastic with copper elements, this filter offers superior safety and heat dissipation. The combination of high insulation resistance and strong dielectric strength ensures secure operation, protecting connected devices and users from electrical hazards caused by surges or leakage currents.

Flexible Installation Options

Featuring both panel mount and inline mounting capabilities, the filter adapts readily to varied installation environments. Screw terminal connectors and copper terminal lugs ensure easy connections. Its compact, customizable size suits different needs, making integration seamless for both residential and industrial applications.

FAQs of Copper Line Filter:

Q: How does the Copper Line Filter remove noise and interference from connected devices?

A: The filter utilizes an internal copper coil and dielectric housing to suppress electromagnetic and radio-frequency interference, providing up to 50dB of noise attenuation. This process ensures that the electrical signals delivered to your appliances are clean and stable, protecting sensitive equipment from performance issues.

Q: What is the recommended process for installing the Copper Line Filter?

A: Installation is straightforward due to its panel mount or inline design. Simply connect your single-phase copper input and output lines using the copper terminal lugs and screw terminals. Ensure the filter is housed securely and observe the rated voltage (230V AC) and current (up to 16A) during setup for best results.

Q: When should I use this filter for my electrical or electronic devices?

A: You should install the Copper Line Filter whenever youre experiencing noise or interference in electrical lines, particularly in environments with air conditioners, refrigerators, telecom equipment, or similar appliances. It is especially useful during initial setup or troubleshooting performance issues linked to line noise.

Q: Where can the Copper Line Filter be deployed for optimal effectiveness?

A: The filter is compatible with most electrical and electronic installations, and can be deployed within control panels, inline with copper power cables, or at the input of sensitive devices. Its robust housing and IP20 rating make it suitable for indoor environments, such as homes, offices, and industrial settings.

Q: What are the benefits of using a flame-retardant housing and copper construction?

A: Flame-retardant plastic and copper offer enhanced thermal conductivity, durability, and fire safety. These materials contribute to stable operation, low risk of overheating, and long-term reliability, making the filter well-suited for demanding electrical environments.

Q: How does the Copper Line Filter achieve instantaneous filtering?

A: The advanced internal copper coil design responds instantly to fluctuating electrical signals, effectively blocking noise and interference as soon as it is detected. This ensures uninterrupted and reliable performance for all connected equipment.

Q: Can the size and capacity of the Copper Line Filter be customized for specific applications?

A: Yes, the filter is available in standard dimensions but can be tailored to meet specific size and capacity requirements, supporting various systems and installation scenarios as requested by the customer.
